T42R-AS1
【 Rated conditions】
| No. | Item | Specification |
| 1 |
Operating Voltage |
6~ 27VDC |
| 2 |
Operating Temperature Range |
-20 ~ +70℃ |
| 3 |
Storage temperature range |
-30 ~ +80℃ |
【 Electrical Characteristics】
| No. | Item | Specification |
| 1 |
Sound Pressure Level |
Min 103dB at 12VDC / 10cm |
| 2 | Resonant Frequency | 3000 ± 500Hz |
| 3 |
Rated current |
20 mA MAX 12VDC |
